| Colorado Climate-Zone and Heating-Design Reference |
| 1 |
Identify the applicable IECC climate zone |
Colorado includes IECC climate zones 4B, 5B, 6B, and 7B. The letter “B” indicates a dry climate classification. |
Use the project address, not the state average. A mountain property and a lower-elevation Front Range property can require different heat-pump capacities. |
Confirm the jurisdiction’s adopted energy code and the county or city climate-zone map. |
| 2 |
Account for elevation and local weather |
Elevation, wind exposure, snow conditions, and local winter temperatures can materially affect heating performance and building heat loss. |
Do not select equipment using only the outdoor temperature shown on a general weather app or a statewide average. |
Use the local heating design temperature from the applicable ASHRAE weather data or an ACCA-compliant load calculation. |
| 3 |
Use the heating design temperature |
A heating design temperature is a statistical outdoor temperature used for sizing; it is not the absolute coldest temperature ever recorded. |
Calculate the design temperature difference with: ΔT = Indoor design temperature − Outdoor heating design temperature |
Document the indoor setpoint, outdoor design temperature, weather station, and edition of the weather data used. |
| 4 |
Calculate conductive heat loss |
Heat loss through walls, windows, ceilings, roofs, floors, and doors is calculated with: Q = U × Area × ΔT where Q is in Btu/h and U is the assembly heat-transfer coefficient. |
Use measured areas and assembly-specific U-values. Do not use a single average insulation value for the entire home. |
Check insulation levels, window specifications, framing, thermal bridges, and below-grade construction. |
| 5 |
Include air leakage and ventilation |
Infiltration heat loss can be estimated with: Q = 1.08 × CFM × ΔT For air changes per hour: CFM = ACH × Volume ÷ 60 |
Cold, dry, windy conditions can increase the effect of uncontrolled air leakage. A blower-door result provides a better input than a generic assumption. |
Use measured blower-door data where available and include required outdoor ventilation air without double-counting it. |
| 6 |
Compare capacity at low outdoor temperatures |
Heat-pump capacity and efficiency vary with outdoor temperature. The relevant value is the delivered heating capacity at the home’s design temperature, not only the nominal rating. |
Review the published performance table at the design temperature and identify whether supplemental heat is expected below the balance point. |
Check low-temperature capacity, operating limits, defrost behavior, auxiliary heat controls, and electrical service requirements. |
| 7 |
Avoid oversizing and verify the installation |
Oversizing can increase cycling, reduce humidity control during cooling, and raise equipment and electrical costs. Undersizing can increase supplemental heat use. |
Match equipment capacity to the calculated design load and verify airflow, refrigerant installation, duct leakage, controls, and commissioning. |
Request a room-by-room Manual J load calculation and a documented startup or commissioning report. |
| Illustrative Design-Heat-Load Calculation — Example Only |
| A |
Example home assumptions |
Conditioned floor area: 2,000 ft² Ceiling height: 8 ft Conditioned volume: 16,000 ft³ Indoor design temperature: 70°F Outdoor heating design temperature: 5°F |
ΔT = 70°F − 5°F = 65°F |
Replace every assumption with project-specific measurements and local design data. |
| B |
Walls |
Opaque wall area: 1,200 ft² Assumed U-value: 0.06 Btu/h·ft²·°F |
0.06 × 1,200 × 65 = 4,680 Btu/h |
Use separate wall areas and U-values for different assemblies. |
| C |
Windows |
Window area: 300 ft² Assumed U-value: 0.30 Btu/h·ft²·°F |
0.30 × 300 × 65 = 5,850 Btu/h |
Use the tested whole-window U-factor, including frame effects where applicable. |
| D |
Roof or ceiling |
Area: 2,000 ft² Assumed U-value: 0.026 Btu/h·ft²·°F |
0.026 × 2,000 × 65 = 3,380 Btu/h |
Account for attic insulation quality, recessed lighting, roof framing, and air-barrier continuity. |
| E |
Floor over unconditioned space |
Area: 2,000 ft² Assumed U-value: 0.04 Btu/h·ft²·°F |
0.04 × 2,000 × 65 = 5,200 Btu/h |
Use a different calculation for slab-on-grade, basement walls, or conditioned crawlspaces. |
| F |
Infiltration example |
Assumed air-change rate: 0.35 ACH Volume: 16,000 ft³ CFM = 0.35 × 16,000 ÷ 60 = 93.3 CFM |
1.08 × 93.3 × 65 = 6,554 Btu/h |
This is an illustrative assumption; measured leakage and required ventilation may produce a different result. |
| G |
Subtotal before distribution adjustment |
Opaque and glazed surface losses plus infiltration: |
4,680 + 5,850 + 3,380 + 5,200 + 6,554 = 25,664 Btu/h |
Internal gains are generally not relied upon to reduce a residential heating design load. |
| H |
Duct and distribution allowance |
Illustrative allowance: 10% of the subtotal for ducts located outside the conditioned space. |
25,664 × 10% = 2,566 Btu/h |
Use actual duct location, insulation, leakage, and distribution factors whenever available. |
| I |
Illustrative total design heating load |
Surface losses, infiltration, and the example distribution allowance: |
25,664 + 2,566 = 28,230 Btu/h Approximately 2.35 tons using 12,000 Btu/h per ton. |
This is not a sizing recommendation. Select equipment from its low-temperature performance data and the completed load calculation. |
